Masonry Screws - TX - Pan - Zinc | 6.0 x 40
£6.13
Skip to product information
Masonry Screws - TX - Pan - Zinc | 6.0 x 40
£6.13
Orders placed before 2pm on working days are normally dispatched the same working day.
Secure online checkout
Genuine TIMCO products
Delivery to eligible UK mainland addresses
Product code: 640MFPAN
A rapid and effective light duty fixing ideal for attaching ironmongery to concrete, stone and brick without the need for nylon plugs. Pan head to improve clamping. Size: 6.0 x 40. Supplied as box. TIMCO product code: 640MFPAN.
Key features
- TX25 TX Drive recess reduces wear & camming-out
- Serrated V-threads to achieve optimum insertion
- High-Low threads for ease of insertion
- All steel, non-flammable fixing conforming to BS 7671 standard's 18th edition, which requires wiring systems to be supported by materials which are unlikely to prematurely collapse in the event of a fire
Technical specification
- Thread Dia. mm: 6
- Length mm: 40
- Recess Type: TX Drive
- Head Type: Pan
- Finish: Zinc
- Drill Hole Dia. mm: 5
- Fixture Hole Diameter mm: 6.5
- Max Fixture Thickness mm: 15
- Min Embedment Depth mm: 25
- Size: 6.0 x 40
- Pack format: Box
- TIMCO product code: 640MFPAN
